Innovate Motorsports MTX Digital Series Dual Function Gauges are 2 1/16 (52mm) gauges featuring interchangeable faceplates and bezels for a user-customized look, locking connectors for simplified installation, and MTS serial connections used to connect with other Innovate devices for logging.
- Error reporting for ethanol content sensor (Digital Display)
- Change exterior LED as a fill bar or light a single indicating LED
- Programmable exterior LED ranges vs. color
- Programmable unit of measure as Fahrenheit or Celsius
- Programmable fuel temperature warning (outer LED)
- 2 Configurable Outputs: Ethanol Content: 0v = 0%, 5v = 100%, Fuel Temp: 0v = -40 Fahrenheit, 5v = 257 Fahrenheit (-40-125Celsius)
- Ethanol Content %: 0-100%
- Temp: -40-257 Fahrenheit (-40-125Celsius)
- MTX-D: Ethanol Content Percentage & Fuel Temp Gauge Kit, includes: Gauge (Black Faceplate, Black Bezel), Silver Bezel & White Faceplate, Harness, Program Cable (Serial), Ethanol Content Sensor, Quick Start Installation Guide.
Attributes:
- Brand Name: Innovate Motorsports
- GTIN:
- Bezel Color: BLACK OR SILVER
- Bezel Style: Innovate
- Cup/Hole Size - Metric - CM: 5.2
- Cup/Hole Size - Standard - IN: 2.0625 in.
- Dial Color: BLACK OR WHITE
- Gauge Type: Dual Gauge - ETHANOL % & FUELT
- Included Wire Harness: 3804
- Includes Sensor Unit: 3907
- Lens Style: Flat, Clear
- Lighting Color: Amber LED/Red Amber Green Segments
- Lighting Type: DIGITAL LED
- Movement: Digital
- Outer Bezel Diameter - Standard: 2.44
- Product Overall Depth: 2.4
- Product Overall Height: 2.44
- Product Overall Width: 2.44
- Product Type: Gauge Ethanol Content / Fuel Temp
- Range: 0 - 100% / -40 - 257 F (-40 - 125Celsius)
- Related Item: 77020
- Size - Metric - CM: 5.2
- Size - Standard - IN: 2.0625 in.
- Upsell: 3906
Extended Information:
- Country of Origin: United States
- Emissions : CARB Eligible
- Life Cycle Status: Available To Order
Packing Information:
- Quantity of Each: 1
- Package UOM: EA
- Weight: 0 POUNDS
